Application:
Sequential sound field reconstruction system, auto-setup with calibrated microphone

Processor:
Wavelet 2 input, 8 output, 56 bit DSP, Room Correction/Stereo Unfold algorithm

System Type:
8 Driver, 4 way system with specialized 3 driver ambient array

Tweeter:
Dual 4 AMT bridge-mounted in post convergent array

Midrange:
1.5 coaxial, titanium/polyester diaphragm, precision waveguide

Midwoofer:
14 carbon/pulp curvilinear cone, neo motor, dipolar

Bass:
Dual 14 carbon/pulp curvilinear cone, neo motor in super cardioid array

Subwoofer:
Dual 12 aluminum diaphragms, 480 oz. motors, cast frame, 3 dual 4 layer voice coils

Passive Radiator:
Dual 12 patented symmetrically loaded with 2 travel

Low Frequency Alignment:
Hybrid cardioid pattern, dual rear radiator, down-firing sub

Inputs:
1 pair binding posts for upper range, 2 XLR balanced for bass, sub, 1 XLR for STEREO UNFOLD

Internal Amplification:
Subs- 1kW, Bass- 750W, Mid-500W, Ambient Array-500W

Recommended Amplification:
1 external channel of 60 watts or greater required for high frequencies

Freq. Response (Hz, /-2dB):
12Hz-30kHz

Impedance:
XLR 10k, binding posts 4 ohms

Sensitivity:
100.5 dB (2.83V@1m)

Crossover (Hz):
65, 800, 6k

Cabinet Dimensions HxWxD (inches):
Cabinet 67 H x 16.25 W x 18 D, Base 1.5 H x 20.75 W x 20.75 D

Weight:
288 lbs each
